Port Pin Assignment E-1

Appendix E: Port Pin Assignments

The tables below lists the pin assignments for the notebook’s various ports.

Table E-1: Parallel Port Pin Assignments

Pin Standard EPP ECP

1 Strobe Write Strobe

2 PData 0 PData 0 PData 0

3 PData 1 PData 1 PData 1

4 PData 2 PData 2 PData 2

5 PData 3 PData 3 PData 3

6 PData 4 PData 4 PData 4

7 PData 5 PData 5 PData 5

8 PData 6 PData 6 PData 6

9 PData 7 PData 7 PData 7

10 Ack Intr Ack

11 Busy Wait Busy, PeriphAck(3)

12 PE (NU) PError,

nAckReverse(3)

13 Select (NU) Select

14 Autofd Datastb AutoFd, HostAck(3)

15 Error (NU) Fault(1),

PeriphRequest(3)

16 Init (NU) Init(1),

ReverseBost(3)

17 Selectin Addrstrb Selectin(1,3)

18-25 Ground Ground Ground
