Front

NOTE: Refer to the illustration that most closely matches your computer.

Component Description

(1) Display release latch Opens the computer.

(2) Wireless light

●

White: An integrated wireless device, such as a wireless

local area network (WLAN) device and/or a Bluetooth®

device, is on.

●

Amber: All wireless devices are off.

(3) Power light ● On: The computer is on.

●

Blinking: The computer is in the Sleep state.

●

Off: The computer is off or in Hibernation.

(4) Battery light

●

Amber: The computer is connected to external power and

the battery is charged from 0 – 90%.

● White: The computer is connected to external power and

the battery is charged from 90 – 99%.

● Blinking amber: A battery that is the only available power

source has reached a low battery level. When the battery

reaches a critical battery level, the battery light begins

blinking rapidly.

●

Off: The battery is fully charged.

18 Chapter 2 External component identification
