CS 9300User Guide

2–4 CS 9300 GENERAL OVERVIEWDigital Sensor LocationFigure 2-3 illustrates the location of the digital sensor of the CS 9300.Figure 2–3 Digital Senso

CS 9300 System User Guide (SM748)_Ed 01 2–5Laser LocationsFigure 2-4 illustrates the location of the lasers of the CS 9300.Figure 2–4 CS 9300 Unit Las

Control Panel2–6 CS 9300 GENERAL OVERVIEWControl PanelThe control panel is an alphanumeric, digital soft touch console. It allows the operator to co

X-Ray Remote Control OverviewCS 9300 System User Guide (SM748)_Ed 01 2–7X-Ray Remote Control OverviewThe x- ray remote control enables you to launch a

Positioning Accessories and Replacement Parts2–8 CS 9300 GENERAL OVERVIEWPositioning Accessories and Replacement PartsThe following accessories are

Positioning Accessories and Replacement PartsCS 9300 System User Guide (SM748)_Ed 01 2–93D Positioning AccessoriesTable 2-2 lists the 3D positioning a

Positioning Accessories and Replacement Parts2–10 CS 9300 GENERAL OVERVIEWPatient Positioning IndicatorsTable 2-3 lists the patient positioning indi

CS 9300 System User Guide (SM748)_Ed 01 3–1Chapter 3IMAGING SOFTWARE OVERVIEWComputer System RequirementsFor the minimum computer system requirements

Acquisition Interface3–2 IMAGING SOFTWARE OVERVIEWAcquisition Interface Panoramic Acquisition OverviewThe Panoramic Acquisition interface is the mai

Acquisition InterfaceCS 9300 System User Guide (SM748)_Ed 01 3–35 Generator Cooling indicator: Indicates the automatic cooling time (mm:ss) required f

NoticeCongratulations on your purchase of the CS 9300. Thank you for your confidence in our products and we will do all in our power to ensure your co

Acquisition Interface3–4 IMAGING SOFTWARE OVERVIEWProgram PaneThe Program pane enables you to choose different radiological exams. The diagram in th

Acquisition InterfaceCS 9300 System User Guide (SM748)_Ed 01 3–5Patient PaneThe Patient Pane enables you to choose different patient parameters. The s

Acquisition Interface3–6 IMAGING SOFTWARE OVERVIEWParameter PaneThe Parameter pane enables you to choose exposure parameters for the radiological im

Acquisition InterfaceCS 9300 System User Guide (SM748)_Ed 01 3–7“Premium” 3D Acquisition Overview The “Premium” 3D Acquisition interface is the optimu

Acquisition Interface3–8 IMAGING SOFTWARE OVERVIEW6 Stop button: Stops the unit rotative arm movement.7 Pre-shoot button: Performs a single scout im

Acquisition InterfaceCS 9300 System User Guide (SM748)_Ed 01 3–93D Program PaneThe 3D Program pane enables you to choose different radiological exams.

Acquisition Interface3–10 IMAGING SOFTWARE OVERVIEWFigure 3–8 Ear Program PaneEar exam options:Right ear: Acquisition of right ear.Left ear: Acquisi

Acquisition InterfaceCS 9300 System User Guide (SM748)_Ed 01 3–11Figure 3–9 Teeth Program PaneFigure 3–10 Jaw Program PaneTeeth setting options:Teeth

Acquisition Interface3–12 IMAGING SOFTWARE OVERVIEWFigure 3–11 TMJ Program PaneTMJ exam options:Right TMJ: Acquisition of right TMJ.Left TMJ: Acquis

Acquisition InterfaceCS 9300 System User Guide (SM748)_Ed 01 3–13Patient PaneThe Patient pane enables you to choose different patient parameters. The

CS 9300 System User Guide (SM748)_Ed 01 iiiContents1—About This GuideConventions in this Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Acquisition Interface3–14 IMAGING SOFTWARE OVERVIEWParameter PaneThe Parameter pane enables you to choose exposure parameters for the radiological i

Acquisition InterfaceCS 9300 System User Guide (SM748)_Ed 01 3–15“Select” 3D Acquisition Overview The “Select” 3D Acquisition interface is the 3D inte

Acquisition Interface3–16 IMAGING SOFTWARE OVERVIEW6 Stop button: Stops the unit rotative arm movement.7 Pre-shoot button: Performs a single scout i

Acquisition InterfaceCS 9300 System User Guide (SM748)_Ed 01 3–173D Program PaneThe 3D Program pane enables you to choose different radiological exams

Acquisition Interface3–18 IMAGING SOFTWARE OVERVIEWFigure 3–16 Jaw Program PaneFigure 3–17 TMJ Program PaneBoth jaws restricted acquisition: Ideal f

Acquisition InterfaceCS 9300 System User Guide (SM748)_Ed 01 3–19Patient PaneThe Patient pane enables you to choose different patient parameters. The

Acquisition Interface3–20 IMAGING SOFTWARE OVERVIEWParameter PaneThe Parameter pane enables you to choose exposure parameters for the radiological i

CS 9300 Imaging System User Guide (SM748)_Ed 01 4–1Chapter 4GETTING STARTEDSwitching on the UnitBefore switching on the unit, check that: The install

Starting the Imaging Software4–2 GETTING STARTED3 Leave the x-ray room and close the door. For each parameter setting, from the x-ray remote control

Starting the Imaging SoftwareCS 9300 Imaging System User Guide (SM748)_Ed 01 4–32 Enter the required patient information. The Last name, the First nam

iv ContentsAcquiring a Panoramic, TMJ x2 or Sinus Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Starting the Imaging Software4–4 GETTING STARTEDStarting the CS Imaging SoftwareTo start the CS Imaging Software, follow these steps:1 On your deskt

Starting the Imaging SoftwareCS 9300 Imaging System User Guide (SM748)_Ed 01 4–54 You can now access the acquisition interface.Accessing the Acquisiti

Starting the Imaging Software4–6 GETTING STARTED

CS 9300 System User Guide (SM748)_Ed 01 5–1Chapter 5ACQUIRING PANORAMIC IMAGESAcquiring a Panoramic, TMJ x2 or Sinus ImageBefore acquiring an image, c

Acquiring a Panoramic, TMJ x2 or Sinus Image5–2 ACQUIRING PANORAMIC IMAGES5. Press and hold to raise the chin rest to the following positioning in

Acquiring a Panoramic, TMJ x2 or Sinus ImageCS 9300 System User Guide (SM748)_Ed 01 5–3Preparing and Positioning the PatientTo prepare and position th

Acquiring a Panoramic, TMJ x2 or Sinus Image5–4 ACQUIRING PANORAMIC IMAGES6. On the Control Panel, click to turn ON the 2 positioning laser beams:

Acquiring a Panoramic, TMJ x2 or Sinus ImageCS 9300 System User Guide (SM748)_Ed 01 5–58. Immobilize the patient head with the temple supports (3). Ti

Acquiring a Panoramic, TMJ x2 or Sinus Image5–6 ACQUIRING PANORAMIC IMAGESLaunching the X-rayTo launch the x-ray, follow these steps:1. Leave the x-

Acquiring a TMJ x4 ImageCS 9300 System User Guide (SM748)_Ed 01 5–7Acquiring a TMJ x4 ImageBefore acquiring a TMJ x4 image, check that you have: Rese

CS 9300 System User Guide (SM748)_Ed 01 1–1Chapter 1About This GuideConventions in this GuideThe following special messages emphasize information or i

X-Ray Dose Emission Information5–8 ACQUIRING PANORAMIC IMAGESX-Ray Dose Emission InformationCompliance with EURATOM 97/43 DirectiveYou can right-cli

CS 9300 System User Guide (SM748)_Ed 01 6–1Chapter 6ACQUIRING 3D IMAGESAcquiring 3D ImagesBefore acquiring 3D images, check that you have: Reset the

Acquiring 3D Images6–2 ACQUIRING 3D IMAGES4. Position the 3D head rest or 3D bite block making sure that it clicks fully into place. 5. Press and ho

Acquiring 3D ImagesCS 9300 System User Guide (SM748)_Ed 01 6–3Preparing and Positioning the PatientTo prepare and position the patient, follow these s

Acquiring 3D Images6–4 ACQUIRING 3D IMAGES5. Position the patient: There are two possible patient positioning options for 3D examinations:3D Bite Bl

Acquiring 3D ImagesCS 9300 System User Guide (SM748)_Ed 01 6–58. Press and hold to align the upper or lower jaw with the 3D FoV (2) positioning lase

Acquiring 3D Images6–6 ACQUIRING 3D IMAGESLaunching the x-rayTo launch the x-ray, follow these steps:1. Leave the x-ray room and close the door. You

X-Ray Dose Emission InformationCS 9300 System User Guide (SM748)_Ed 01 6–7X-Ray Dose Emission InformationCompliance with EURATOM 97/43 DirectiveYou ca

X-Ray Dose Emission Information6–8 ACQUIRING 3D IMAGES

CS 9300 System User Guide (SM748)_Ed 01 7–1Chapter 7MAINTENANCECleaning ScheduleThis section describes the cleaning schedule that you need to perform

Conventions in this Guide1–2 About This Guide

Monthly7–2 MAINTENANCEMonthlyWipe the outer covers of the unit with a soft and dry cloth.AnnuallyWe recommend a general inspection of the unit carri

Controlling the Image QualityDRAFT CS 9300 System User Guide (SM748)_Ed 01 7–33. In the Too l s pane, double-click Quality Assurance Control. The Imag

Controlling the Image Quality7–4 MAINTENANCE

CS 9300 System User Guide (SM748)_Ed 01 8–1Chapter 8TROUBLESHOOTINGQuick TroubleshootingOccasionally, malfunctions can occur during use in the event o

Quick Troubleshooting8–2 TROUBLESHOOTINGI 6 Wrong rotative arm positionThe exposure button of the x-ray remote control is inactive because the rotat

CS 9300 System User Guide (SM748)_Ed 01 2–1Chapter 2CS 9300 GENERAL OVERVIEWThe CS 9300 is composed of the following functional components: The unit

2–2 CS 9300 GENERAL OVERVIEWMobile ComponentsFigure 2-1 illustrates the up and down movement of the CS 9300 mobile components and the 180° rotation

CS 9300 System User Guide (SM748)_Ed 01 2–3General Functional ComponentsFigure 2-2 illustrates the general functional components of the CS 9300.Figure
