Problems Related to Paper Feeding and Output
The displayed bypass
tray paper size is not
correct.
Is the bypass tray extension pulled out? When loading paper in the bypass tray, be sure to pull
out the extension to enable the paper size to be
detected correctly.
☞ Illustration of the machine (H) (page 36)
Problem Point to check Solution
The original misfeeds. Is the original on thin paper?
(When the automatic document feeder
is used.)
Use the document glass to scan the original. If you need
to use the automatic document feeder, use slow scan
mode in the special modes to scan the original.
Is the feed roller dirty? Clean the surface of the original feed roller.
☞ "5. MAINTENANCE" in the User's Guide
The paper misfeeds. Is a torn piece of paper remaining in the
machine?
Make sure all paper is removed.
☞ REMOVING MISFEEDS (page 3)
Is too much paper loaded in the tray? Make sure that the stack of paper in the tray is not
higher than the indicator line.
☞ Illustration of the machine (E) (page 36)
Are multiple sheets feeding at once? Fan the paper well before loading it.
Are you using paper that is not within
the specifications?
Use SHARP-recommended paper. Using paper that is not
supported may result in misfeeds, creases, or smudges.
☞ "SUPPLIES" in the Safety Guide
* For paper that is prohibited or not recommended, see
"USEABLE PAPER" in the User's Guide.
Has the paper in the tray absorbed
moisture?
If you will not be using paper in a tray for a long time,
remove the paper from the tray and store it in a bag in a
dark and dry location.
Are the bypass tray guides adjusted to
the width of the paper?
Adjust the bypass tray guides to the width of the paper.
☞ Illustration of the machine (F) (page 36)
Is the bypass tray extension pulled out? When loading a large size of paper, pull out the
extension.
☞ Illustration of the machine (H) (page 36)
Is the bypass tray feed roller dirty? Clean the surface of the bypass tray feed roller.
☞ "5. MAINTENANCE" in the User's Guide
Problem Point to check Solution
