Copier trouble?

MISFEED REMOVAL

A Misfeed in the paper feed area

Gently remove the misfed paper from the paper feed area as shown in the illustration.

When blinks in the display and the misfed paper is not seen from the paper feed

area, pull out the paper tray and remove the misfed paper. If the paper cannot be

removed, proceed to “B Misfeed in the fusing area”.

The fusing unit is hot. Do not touch the fusing unit when removing misfed

paper. Doing so may cause a burn or other injury.

●

Do not touch the surface of the drum (green portion) of the drum cartridge

when removing the misfed paper. Doing so may damage the drum and cause

smudges on copies.

●

If the paper has been fed through the manual bypass, do not remove the

misfed paper through the manual bypass. Toner on the paper may stain the

paper transport area, resulting in smudges on copies.

Close the side cover by pressing the round projections near the side cover open

button. The misfeed ( ) indicator will go out and the ready ( ) indicator will light

up.

B Misfeed in the fusing area

Lower the fusing unit release lever.

Fusing unit release lever

Gently remove the misfed paper from under the fusing unit as shown in the illustration.

If the paper cannot be removed, proceed to “C Misfeed in the transport area”.

The fusing unit is hot. Do not touch the fusing unit when removing misfed

paper. Doing so may cause a burn or other injury.
