4-1

CHAPTER4

CHAPTER 4

SUPPLIES

This chapter describes the supplies for this copier such as paper and

toner.

Page

●●

●

PAPER ......................................... 4-2

Types and sizes of copy paper ......................... 4-2

Loading copy paper ................................ 4-2

●●

●

ADDING TONER .................................. 4-5

●●

●

USED TONER DISPOSAL ........................... 4-8

●●

●

STORAGE OF SUPPLIES ........................... 4-9
