ADVANCED TRANSMISSION METHODS
Serial polling
When performing serial polling, an auto-dial key that includes a sub-address or passcode (page 48) cannot be
selected.
1
Perform steps 1 to 3 of the polling
procedure (page 37).
2
Select "SERIAL POLLING" with the
[ ] or [ ] key.
About the steps that follow
See steps 5 to 8 of the polling procedure (page 37).
Before pressing the [START] key in step 8, repeat
steps 6 and 7 for each machine that you wish to poll.
When performing serial polling, a group key can also
be used in step 6 on page 37.
GH
PQR
2-SIDED
COPY
SPECIAL FUNCTION
SENDING OPTIONS
POLLING
SERIAL POLLING
SUB ADDRESS TX
