Programming Auto-Dial Numbers
40
3
Press . Make sure that SET is
selected.
4
Press .
5
To program a Rapid Key number, press the Rapid Key that you wish to
use. (To select Rapid Keys 40 through 59, flip up the Rapid Key overlay.)
To program a Speed Dial number, press and then enter the
number that you wish to use (“1” to “100” on the FO-DC500, or “1” to
“200” on the FO-DC600). (If you enter less than three digits, press
to complete the entry.)
6
If the network scanner option is installed, SELECT DESTINATION TYPE
will appear in the display. Make sure that “FAX” is selected (press
or if needed), and then press .
(To program an e-mail address in an auto-dial number, see page 87.)
7
Enter the fax number by pressing the numeric keys (maximum of 60
digits including pauses).
• To clear a mistake, press .
• If a pause is required between any of the digits to access a special service
or an outside line, press (two seconds per pause). The pause will
appear as a hyphen. Several pauses can be entered in a row.
8
Press .
START/
ENTER
START/
ENTER
SPEED DIAL
START/
ENTER
START/
ENTER
DEL
REDIAL
START/
ENTER
DESTINATION SETTING
1=SET
2=CLEAR
DESTINATION SET
PRESS RAPID OR SPEED
all.bookPage40Wednesday,December18,20028:17AM
