FUNCTIONS THAT COMBINE TEXT AND
IMAGES
ADDING A WATERMARK TO PRINTED PAGES
(Watermark)
Faint shadow-like text can be added to the background
of the printed image as a watermark. The size and angle
of the watermark text can be adjusted. The text can be
selected from a pre-stored list, or entered to create an
original watermark.
(1) Click the [Watermarks] tab.
(2) Select the watermark settings.
Select a stored water mark from the pull-down menu. You
can click the [Edit] button to edit the font and select other
detailed settings.
Mac OS X
(1) Select [Watermarks].
(2) Click the [Watermark] checkbox and
configure watermark settings.
Detailed watermark settings can be configured such as
selection of the text and editing of the font. Adjust the size
and angle of the text by dragging the slide bar .
CONFIDENTIAL
Windows
(1)
(2)
If you wish to create a new watermark...
Enter text in "Text" and click [Edit] to adjust the text.
[Add] can be clicked to store the watermark for
convenient reuse in the future. (The size adjustment
and angle information will also be stored.)
Macintosh
(1)(2)
In Mac OS X v10.1.5, adjust the watermark settings on
the [Watermarks] tab of [Printer Features].
