STAPLE FUNCTION / SADDLE STITCH FUNCTION
When a finisher or saddle stitch finisher is installed, the loaded paper can be stapled into a sheaf. (Staple function)
When a saddle unit or saddle stitch finisher is installed, the paper can be stapled in two places on the centerline and
folded to make a pamphlet. (Saddle stitch function)
For the sizes and number of paper sheets that can be stapled at once, see the specifications in the Safety Guide.
Staple function
Touch the [Staple] key in the manual finishing screen to display the following screen.
Touch the key of the desired stapling position.
4
5
Saddle stitchStaple
Fold
2 Hole
Punch
3 Hole
Punch
Offset Tray
Staple
Slant Staple
Top Tray
Plain
8½x11
Plain
8½x11
Set the output function.
