Transmission time
Approx. 2 seconds *1 (A4 (8-1/2" × 11") Sharp standard paper, normal
characters, Super G3 (JBIG))
Approx. 6 seconds (G3 ECM)
Memory 1 GB
Notes
Touch dial memory Max. of 2,000 entries (Including group dialling for fax,
scanner, and Internet fax)
Entries per group Max. of 500 entries
Mass transmissions Max. of 500 recipients
*1 Complies with the 33.6 kbps transmission method for Super G3 facsimiles standardized by the International
Telecommunications Union (ITU-T). This is the speed for when sending an A4 (8-1/2" × 11") size piece of paper
of around 700 characters at standard image quality (8 × 3.85 line/mm) in Hi-speed mode (33.6 kbps). This is the
transmission speed for image information only and does not include time for transmission control. The actual time
needed for a transmission depends on the content of the text, type of receiving fax machine, and telephone line
conditions.
Name Facsimile expansion kit (MX-FX11)
Useable lines General phone lines (PSTN), private branch exchange (PBX)
Scanning line density
Normal characters: 8 dot/mm × 3.85 line/mm
Small characters: 8 dot/mm × 7.7 line/mm
Fine characters: 8 dot/mm × 15.4 line/mm
High-denition: 16dot/mm×15.4line/mm
Connection speed Super G3: 33.6 kbps, G3: 14.4 kbps
Coding method MH, MR, MMR, JBIG
Connection mode Super G3 / G3
Original paper sizes for transmission
A3 (11" × 17") to A5 (5-1/2" × 8-1/2") (Paper with a max. length of 1,000 mm*
can be transmitted (one-sided and B/W only).)
Registered paper size A3 (11" × 17") to A5 (5-1/2" × 8-1/2")
Fax Specications
Type Built-in type
Continuous print speed Same as continuous copy speed
Resolution
Data processing: 600 × 600 dpi, 1,200 × 1,200 dpi
Print: 600 × 600 dpi, equivalent to 9,600 dpi × 600 dpi, 1,200 × 1,200 dpi
Page description language Standard: PCL6 emulation, Adobe
®
PostScript
®
3
Compatible protocols TCP/IP, IPv4/IPv6, IPX/SPX, NetBIOS, IPP, EtherTalk
Compatible OS
Windows XP, Windows Server 2003, Windows Vista, Windows Server 2008,
Windows 7, Windows Server 2008R2 *
Macintosh (Mac OS × 10.4 ~ 10.4.11, 10.5 ~ 10.5.8, 10.6.5 ~ 10.6.8, 10.7 ~ 10.7.2)
Internal fonts (options) 80 fonts for PCL, 136 fonts for Adobe
®
PostScript
®
3
Memory Machine system memory and hard disk
Interface 10BASE-T/100BASE-TX/1000BASE-T, USB 1.1, USB 2.0 (high speed mode)
*: There are cases when a connection cannot be established. Please contact your local dealer for more information.
Network Printer Specications
Name Punch module
MX-PN12A, MX-PN12B, MX-PN12C, MX-PN12D
Paper size for punch module A3 (11" × 17") to B5R (7-1/4" × 10-1/2"R)
Holes
MX-PN12A: 2 holes MX-PN12C: 4 holes
MX-PN12B: 3 holes MX-PN12D: 4 holes (wide)
Required power supply Suppliedfromnisher/saddlestitchnisher
Dimensions
102 mm (W) × 662 mm (D) × 914 mm (H)
(4-1/64" (W) × 26-1/8" (D) × 36" (H))
Weight Approx. 8 kg (17.6 lbs.)
Punch module (MX-PN12A, MX-PN12B, MX-PN12C, MX-PN12D)
Name Punch module
MX-PN13A, MX-PN13B, MX-PN13C, MX-PN13D
Paper size for punch module A3 (11" × 17") to B5R (7-1/4" × 10-1/2"R)
Holes
MX-PN13A: 2 holes MX-PN13C: 4 holes
MX-PN13B: 3 holes MX-PN13D: 4 holes (wide)
Required power supply Suppliedfromnisher/saddlestitchnisher
Dimensions
95 mm (W) × 715 mm (D) × 392 mm (H)
(3-47/64" (W) × 28-5/32" (D) × 9-13/32" (H))
Weight Approx. 3.7 kg (8.2 lbs.)
Punch module (MX-PN13A, MX-PN13B, MX-PN13C, MX-PN13D)
SPECIFICATIONS
