FO-1MK

No. 00ZFO1MKCUSME

CONTENTS

MODEL FO-1MK

Parts marked with " " is important for maintaining the safety of the set. Be sure to replace these parts with specified ones for

maintaining the safety and performance of the set.

This document has been published to be used

for after sales service only.

The contents are subject to change without notice.

SHARP CORPORATION

SERVICE MANUAL

FACSIMILE

OPTION MEMORY

UPGRADE PWB

[1] General description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

[2] Installation procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

[3] Diagnostic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

[4] Circuit schematics and parts layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

[5] Parts guide

1 2 3 4 5 6 7 8

Inhaltsverzeichnis

Seite 1 - SERVICE MANUAL

1 - 1FO-1MKNo. 00ZFO1MKCUSMECONTENTSMODEL FO-1MKParts marked with " " is important for maintaining the safety of the set. Be sure to replace

Seite 2 - [3] Diagnostic mode

FO-1MK– 1 –[1] General descriptionThis machine is an option memory unit applicable to the machinesFO-4700 (100 or 200V series). It enhances the memory

Seite 3 - CONTROL PWB

FO-1MK– 2 –Then, the result table (Fig. 3) is printed.In case of mismatch, the buzzer emits 9 short tones .After that, the result table (Fig. 4) is ou

Seite 4 - HRW0502A

FO-1MK126435BDEFGIHCABDEFGIHCA1264354567810111213171819202223242627285250474541393634514946444038353314255A19A18A17A16A15A14A13A12A11A10D15D14D13D12D1

Seite 5

FO-1MK– 4 –126435BDEFGIHCABDEFGIHCA126435456781011121317181920222325262752504745413936345149464440383533142A19A18A17A16A15A14A13A12A11D14D13D12D10D9D8

Seite 6

FO-1MK– 5 –126435BDEFGIHCABDEFGIHCA126435DGDG+5V+5VD14D12D10D8D6D4D2D0MA18MA16MA14MA12MA10MA8MA6MA4MA2FLBK4FLBK1FLBK3DGTCS2/MWRH/MRD/FLBSYD15D13D11D9D

Seite 7

FO-1MKOption memory PWB parts layout (Top side)Option memory PWB parts layout (Bottom side)– 6 –

FO-1MKSHARP CORPORATIONCommunication Systems GroupQuality & Reliability Control CenterHigashihiroshima, Hiroshima 739-0192, JapanPrinted in JAPAN9
