5 - 6

(4) Speed data (No.01 to 64)

Setting range: 0 to 500000 (0 to 500 kpps) in 1-pps increments

Address

6543210

Bit

G+0000

G+0001

G+0002

G+0003

• G is the top address of each speed data No.01 to 64.

(5) Position data (No.01 to 99)

Setting range: -9999999 to +9999999 (-9999999 to +9999999 pulses) in 1-pulse increments

"A/I": 0=absolute value, 1=relative value, "Sign": Plus=0, Minus=1

• H is the top address of position data No.01 to 99.

• Position instructions at writing of interrupt output position data becomes an absolute value regardless of

the setting of "A/I", and "A/I" becomes the bit for specifying interrupt output ON/OFF.

(When "A/I" is set to "1", interrupt output is ON, and when "A/I" is set to "0", interrupt output is OFF.)

• Position instructions at speed control startup become the travel distance after an interrupt, and the

"Sign" and "A/I" bits are disabled.

Address

654

A/I Sign

3210

Bit

H+0000

H+0001

H+0002

H+0003
