INSTALLING THE TD CARTRIDGE

Push gently on both ends of the front

cover and open it.

Remove the new TD cartridge from the

bag. Hold the cartridge on both sides

and shake it horizontally four or five

times.

Remove the protective cover from the

TD cartridge by unlatching three

cover hooks from the holes on the

cartridge and then pulling the cover in

the direction indicated by the arrow in

the illustration.

Insert the TD cartridge along the

guides until it locks in place.

If there is any dirt or dust

on the TD cartridge,

remove it before

installing the cartridge.

Close the front cover.

The TD cartridge

replacement required

indicator ( ) will go out.

4 or 5 times

• Before closing the front cover, make sure

that the TD cartridge is correctly installed.

• When closing the front cover, gently hold

both ends.

Note

AL-1633_1644_EX.book 14 ページ２００３年１０月２３日　木曜日　午後８時２１分
