TROUBLESHOOTING AND MAINTENANCE

Close the front cover and

then the side cover by

pressing the round

projections near the side

cover open button. The error

indicator will go out and the

ready indicator will light up.

SCAN HEAD LOCKING SWITCH

The scan head locking switch is under the original table. If the switch is locked ( ),

the unit will not operate. Unlock the switch ( ) as shown below.

When closing the covers, be sure to close the front cover securely and

then close the side cover. If the covers are closed in the wrong order,

the covers may be damaged.

Even after a new toner cartridge is installed, the start ( ) indicator

may not light up, indicating copying cannot be restarted (toner is not

sufficiently fed). In this case, open and close the side cover. The copier

will feed toner again approximately 2 minutes and then copying can be

restarted.

Caution

Note

Lock Unlock

Grasp here and turn in

the direction of the arrow.
