250-SHEET PAPER FEED UNIT (AR-D16)

The paper feed unit provide the convenience of increased paper capacity for the unit

and a greater choice of paper size readily available for copying.

The procedures for loading paper in the

paper tray of paper feed unit, changing

the paper size, and selecting the paper

tray are same as for the paper tray in the

unit. See "LOADING THE PAPER TRAY"

(p.15) and "SELECTING THE TRAY"

(p.23).

Misfeed removal

The copier will stop when a misfeed ocurs. The misfeed ( ) indicator blinks or

blinks in the display.

Open the lower side cover (under the

bypass tray) and remove the misfed

paper. If blinks and the misfed

paper is not seen from the area of the

lower side cover, pull out the lower

paper tray and remove the misfed

paper. Then close the lower paper

tray.

Close the lower side cover.

Close the side cover by pressing the round projections near

the side cover open button. The misfeed ( ) indicator will go

out and the ready ( ) indicator will light up.

Lower side cover

Tray
