STATUS

INDICATORS

MISFEED REMOVAL

Misfeed removal

Close the side cover by pressing the handle on the

cover.

●

The misfeed ( ) indicator will go out.

Misfeed in the upper paper tray

Before opening the upper paper tray, be sure to open the bypass tray, lift

slightly on the side cover and slide the cover out until it stops, and then

perform steps 1 to 3 described in the “A. Misfeed in the paper feed area”

section.

Gently lift and pull out the upper paper tray and remove

the misfed paper.

Close the paper tray.

Lift slightly on the side cover and slide the cover out

until it stops. Close the side cover by pressing the

handle on the cover.

●

The misfeed ( ) indicator will go out.
