OPTIONAL EQUIPMENT

Press and hold down the ORIGINAL TO COPY key for

approximately 5 seconds until the indicator will

blink and the currently selected parameter number will

blink in the copy quantity display.

Select the desired parameter using the numeric keys.

●

0: OFF 1: ON

The factory default setting is 0.

Press the START key.

●

The selected parameter will be steadily lit.

Press the ORIGINAL TO COPY key.

●

The indicator will stop blinking.

The image rotation in duplex copying can be also set

using user program No. 20. See page 38.

Setting image rotation in duplex copying

SINGLE PASS FEEDER

(

AR-SP2

)/REVERSING SINGLE PASS FEEDER (AR-RP1)

Single pass feeder (AR-SP2)

Reversing single pass feeder (AR-RP1)
