CONNECTING TO A COMPUTER

Connecting a usb cable

Please purchase a USB cable (shielded) that complies

with the following standard.

The USB interface on the machine complies with the

USB 2.0*/1.1 standard.

* when the dual function board is installed.

Connecting a parallel cable

Please purchase a Centronics cable (shielded) that

complies with the following standard.

The parallel port on the machine complies with

IEEE-STD-1284-1994 ECP.

Connector type (on the machine):

36-pin Amphenol female connector

Connecting to a network connector

If the machine will be used as a network computer,

read the online manual on the "Network Utilities"

CD-ROM that accompanies the network expansion kit

(AR-NB3).

Use a network cable that is shielded.

USB-2:

USB 2.0 port

USB-1:

USB 1.1 port

• The machine's USB 2.0 port will transfer data at the speed specified by the USB 2.0 only if the Microsoft USB

2.0 driver is preinstalled in the computer, or if the USB 2.0 driver for Windows 2000 Professional/XP that

Microsoft provides through "Windows Update" is installed.

• To obtain the full USB 2.0 data transfer speed, "USB2.0 mode" in the machine's key operator programs must

be set to "Hi-Speed". For more information, see the "Key operator's guide".

• Use the machine's "Hi-Speed" mode only when using a computer that is running Windows 2000/XP/Server

2003.

• Even when the Microsoft USB 2.0 driver is used, it may not be possible to obtain full USB 2.0 speed if a PC

card supporting USB 2.0 is used. To obtain the latest driver (which may enable a higher speed), contact the

manufacturer of your PC card.

• The cable can also be inserted into a USB 1.1 port. However, performance will be the same as USB 1.1.

Note

Chapter03.fm 44 ページ２００４年９月４日　土曜日　午後５時３２分
