128

10. Maintenance

Fax print head

Clean the printing head frequently to assure optimum printing

performance.

First unplug the telephone line, then unplug the power cord.

Open the operation panel (grasp the finger hold and pull up), and then

pull the release on the right side of the machine forward to open the

print compartment cover.

Pull the paper release plate forward and remove the paper.

For Australia

For New Zealand
