Preparing Cartridges
A-2 Tenth Edition 9871
Inspecting a Cartridge
A defective or dirty cartridge can damage a tape drive or transport. Always
inspect a cartridge before inserting it into a tape drive, inserting it into a tape
transport, or entering it into an LSM. See Figure A-1 through Figure A-6 on
page A-5. Look for:
• Cracked or broken cartridge
• Broken leader block
• Broken leader block latch
• Damaged file protect selector
• Liquid in the cartridge
• Labels not firmly attached or extending over the cartridge edge
• Any other obvious damage
Figure A-1. 3480 Cartridge Locations
LEADER
BLOCK
FILE
PROTECT
SELECTOR
LABEL
S
C
4
0057
