3-21
Basic Operation
Send to Folder (SMB)/Send to Folder (FTP)
Stores a scanned original image file in the specified shared folder of any PC.
Stores a scanned original image in a folder of an FTP server.
NOTE:
• Refer to Help of your operating system for details on how to share a folder.
• Be sure that SMB Protocol or FTP in the Embedded Web Server is On. For details, refer to the Embedded Web
Server Operation Guide.
• Refer to Character Entry Method on Appendix-5 for details on entering characters.
1 Press the Send key.
Displays the screen for sending.
2 Place the originals on the platen or in the document
processor.
NOTE: For loading instructions, refer to Loading
Originals on page 2-52.
3 Press the U or V key to select [Folder(SMB)] or
[Folder(FTP)].
4 Press the OK key. Host Name(SMB) or Host Name(FTP)
appears.
5 Enter the host name.
NOTE: Destination can be specified using the Address
Book or the One-touch keys. Refer to Specifying
Destination on page 3-25.
6 Press the OK key. Path appears.
Send to:
a
b
1
p
E-mail
*********************
3
H
Folder(FTP)
2
G
Folder(SMB)
Host Name(SMB):
A
b
RD Center
*
ABC
[ Text ]
Host Name(FTP):
A
b
RD Center
*
ABC
[ Text ]
or
