A-105 Color Measurement Instruments

Sharp AR-C360P EFI Color Guide - 105

Using the X-Rite DTP32 densitometer

ColorWise Pro Tools are designed to work with the X-Rite DTP32

reflection densitometer, which feeds color measurements to the

Fiery automatically.

Note:Measurements from other densitometers can be input using

a simple ASCII file format (see Appendix B).

Setting up the DTP32

Before you calibrate the Fiery using the X-Rite DTP32, you need to

connect, configure, and calibrate the densitometer to prepare for

measuring the printed patches (see “Calibrating the DTP32” on

page A-107). For additional information about setting up and

using the DTP32, see the separate documentation included with

the densitometer.

To connect the X-Rite DTP32 to the computer

1. Turn off the computer.

2. Plug the square end of the interface cable (looks like a modular

phone plug) into the I/O port on the side of the X-Rite DTP32.

Square

connector
