■ Standard original setting orientation
Descriptions of functions that follow in this manual assume that originals are oriented as shown.
Document feeder tray Document glass
■■
■■
■ Automatic copy image rotation - rotation copying
If the orientation of the originals and copy paper are different, the original image will be automatically rotated 90°
and copied. (When an image is rotated, a message will be displayed.) When enlargement of originals larger than 8-
1/2" x 11" or A4 is selected, rotation cannot be done.
[Example]
●
This function operates in the auto paper select or auto image mode. (Rotation copying can be disabled
with a key operator program. See page 33.)
Orientation of original Orientation of paper Copy after rotation
Face down Face down
Place originals in the document feeder tray or on
the document glass so that the top of the original
is positioned to the rear side of the machine. If
not, staples will be incorrectly positioned and
some special features may not give the expected
result.
SETTING ORIGINALS
To p
To p
To p
Bottom
Bottom
Bottom
To p
Bottom
copy-1_Ep.P65 2/04/01, 19:178
