0-4

CAUTIONS

Cautions on laser

Wave length

785 nm

+10 nm

−15 nm

Pulse times North America: 35 cpm model: (4.1 µs ± 4.1 ns)/7 mm

45 cpm model: (5.7 µs ± 5.7 ns)/7 mm

Europe: 35 cpm model: (3.8 µs ± 3.8 ns)/7 mm

45 cpm model: (4.4 µs ± 4.4 ns)/7 mm

Output power 0.2 mW - 0.4 mW

At the production line, the output power of the scanner unit is adjusted to 0.4

MILLIWATT PLUS 8 % and is maintained constant by the operation of the Automatic

Power Control (APC).

Caution

This product contains a low power laser device. To ensure safety do not remove any cover or attempt to gain

access to the inside of the product. Refer all servicing to qualified personnel.

For North America:

SAFETY PRECAUTIONS

This Digital Equipment is rated Class 1 and complies with 21 CFR 1040.10 and 1040.11 of the

CDRH standards. This means that the equipment does not produce hazardous laser radiation. For

your safety, observe the precautions below.

●

Do not remove the cabinet, operation panel or any other covers.

●

The equipment's exterior covers contain several safety interlock switches. Do not bypass any

safety interlock by inserting wedges or other items into switch slots.

Caution

Use of controls or adjustments or performance of procedures other than those specified herein may result in

hazardous radiation exposure.
