5-3

Loading paper in the bypass tray

The bypass tray can be used for plain paper and special papers including labels. Up to 100 sheets of standard paper

can be set. For paper types that can be used in the bypass tray, refer to page 1-17.

NOTE

If the paper type or size is changed, be sure to enter the paper type and size as in step 4.

Open the bypass tray.

When setting 11"x 17",

8-1/2" x 14", 8-1/2" x 13,

A3 or B4 paper, be sure

to extend the bypass tray

extension.

Set the bypass tray paper guides to the

width of the paper to be used.

Insert the paper all the way into the bypass

tray.

Set the paper face down.

If there is a clearance

between the paper and

the paper guides, the

paper may not be fed

correctly. Adjust the

guides so that they

contact the edges of the

paper.

NOTES

●

When using 5-1/2" x 8-1/2" paper, A5 paper or

postcards, be sure to load them with their shorter

edge into the feed slot as shown in the illustration.

●

When using special paper, postcards or

transparency film, be sure to feed them one

sheet at a time. If you set more than one sheet,

a paper misfeed may occur.

●

When adding paper, first remove remaining

paper, combine it with the paper to be added,

and then reload as a single stack. Adding paper

without stacking it correctly may cause a paper

misfeed.

●

When printing onto transparency film, remove

the output sheets as soon as possible.

●

For transparency film, use SHARP recom-

mended film.

Set the type and size of the loaded paper.

When the paper system is changed from the inch

system to the AB system or vise versa or when the

paper type is changed, the paper type must be

designated. For setting the paper size and type, see

page 1-19.

Loading paper in the bypass tray is now

complete.

DUPLEX MODULE

Bypass tray extension
