Afteryounishtheservicing,makesurethatyouinsertthecardbackintotheslotrmly.

1090Palmrestassemblywithcables

Foraccess,removetheseFRUsinorder:

•“1010Batterypack”onpage58

•“1020Opticaldriveortravelcover”onpage58

Note:Inmodelswiththengerprintreader,thesensorisattachedtothepalmrestFRU.Ifthengerprint

readerhasanydefects,youcanreplaceitbytheproceduresgiveninthissection,whicharethesame

forapalmrestwithorwithoutangerprintreader.

Chapter8.RemovingorreplacingaFRU69
