•“1020Opticaldriveortravelcover”onpage58

•“1090Palmrestassemblywithcables”onpage69

RemovalstepsofthePCIExpressMiniCardforwirelessLAN

Instep1aand1b,unplugtheconnectorssbyusingtheremovaltoolantennaRFconnector(P/N:08K7159)

orpicktheconnectorswithyourngersandgentlyunplugthemindirectionofthearrow.

StepScrew(quantity)Color

Torque

M2×3mm,wafer-head,nylon-coated(2)

Black0.181Nm

(1.85kgf-cm)

Chapter8.RemovingorreplacingaFRU73
