Timetable Editor

Importing a timetable

TheimportfunctionisusedtoloadanexportedtimetablethathasbeencreatedwiththisproductonanotherPC.

1. From the [File] menu, click [Import Timetable].

The[Selectthetimetabletoimport]dialogboxwillappear.

2. Select a (.tbl) le to import, and click [Open].

The[ImportTimetable]dialogboxwillappear.

A screen like the one on the right will appear while

theimportisbeingprepared.Click[Cancel]to

cancel the import.

3. Select the timetable folder in which the timetable is to be

saved.

4. Enter a “Timetable Name” and click [Import].

 IfthesameprogramalreadyexistsonthePC

wheretheimportistobeused,aconﬁrmation

dialogboxwillappear.Choosewhethertooverwrite

theexistingﬁleorimporttheﬁleunderanewname.

5. Click [Yes].

The timetable will be saved with the name you entered.

The timetable import is now complete.

Creating a timetable
