Schedule Distribution Tool

Distributing schedules

5. Check the distribution settings, and click [Finish].

Thedistributionwillbeexecuted.

Distribution data can be packaged and saved as

asingleﬁlethatincludesscheduleinformation

including programs, timetables, and content.

Click[SavethePackage],andinthe[Savethe

Package]dialogboxthatappears,specifya

directorytosavetheﬁleto.Thenentera“File

name”,andclick[Save].Thereisusuallynoneedto

use this function.

6. A screen like the one on the right will appear. Check that

the distribution was successful and click [Close].

●Distributing with USB memory or other external storage device

 •DonotremovetheUSBmemoryorotherexternalstoragedevicefromyourPCuntilthetransferis

complete.

•CertainUSBdevicesandotherexternalstoragedevicesmaynotbeabletodistributecorrectly.

•SetthetargetPCto“Normalmode.”Ifitissetto“Contentsdirectdistributemode,”schedulescannotbe

distributed (

p.103).

1. Click [Distribute schedule or program to the panel].

The[SelectionofDistributionMethods]dialogboxwillappear.

2. Select the “Distribute the schedule using external

storage such as USB memory” option button, and click

[Next].

The[SelectiontheScheduletoDistribute]dialogboxwill

appear.
