Schedule Distribution Tool

11. If you selected the “Distribute now” option button in step

7, a screen like the one on the right will appear. Check

that the distribution was successful and click [Close].

If you selected the “Distribute at specied date time”

option button in step 7, a screen like the one on the right

will appear. Click [OK].

 •Scheduleandprogramdistributionmaytakesometime.Ifyouperformsimultaneousdistributionto

multiplepanels,dataisactuallysentsequentially.Forthisreason,theremaybesometimedifferencein

schedule and program distribution.

•Oldschedulesarenolongerrequiredafternewscheduleshavebeensent.Unnecessaryschedulesand

theirassociatedcontentwillbeautomaticallydeletedthenexttimeClientSchedulerstarts.

●Distributing to your own PC

These instructions only apply to the Standalone Version.

1. Click [Distribute schedule or program to the panel].

The[SelectionofDistributionMethods]dialogboxwillappear.

2. Select the “Distribute the schedule to your PC (My

computer)” option button, and click [Next].

The[SelectiontheScheduletoDistribute]dialogboxwill

appear.

3. Select a schedule.

If you want to add the selected schedule to the current open

scheduleonyourPC,checkthe“Addthisscheduleonthe

runningscheduleinthetargetpanel”checkbox.Iftheboxis

notchecked,thecurrentlyopenscheduleonyourPCwillbe

replaced with the currently selected schedule.

4. Click [Next].

A[Conﬁrmation]dialogboxwillappear.

Distributing schedules
