SPECIAL MODES
5-23
5
Transparency film with insert sheets
When copying onto transparency film, blank insert sheets can be placed between transparent sheets.
●
This function only operates in "one-sided to one-
sided" and "two-sided to one-sided" modes.
● Multiple copies cannot be selected in this mode.
●
The inserts are inserted under each transparency
as shown at left.
●
Select insert paper that is the same size as the
transparencies.
● Transparencies can be fed from the tray 2 or
bypass tray.
●
If the transparencies are loaded in tray 2, be sure
to set the paper size and paper type as explained
on pages 2-5 and 2-6.
1
Load transparency film into the tray 2.
Remove any paper
already in the tray 2
before loading the
transparency film. (To
load paper in the tray 2,
see pages 2-6 and 2-7.)
2
Press the [SYSTEM SETTINGS] key.
The system settings
menu screen will
appear.
3
Touch the [PAPER TRAY SETTINGS] key.
The paper tray selection
screen will appear.
4
Touch the [TRAY SETTINGS] key.
5
Touch the key to display the tray
settings screen of tray 2.
6
Touch the [TYPE/SIZE] key.
7
Touch the [TRANSPARENCY] key.
8
Touch the [OK] key.
If the paper size was changed from an inch size to an
AB size, or from an AB size to an inch size, be sure
to set the paper type and size as explained on steps
5 to 6 on page
2-5
and steps 7 to 10 on page
2-6
.
Insert sheets
Example: Inserting insert sheets between transparencies
Originals (1-sided)
Originals (2-sided)
Two-sided originals are only
supported when automatic
document feeder is used.
Inserts can also be
copied on.
PY
JOB STATUS
SYSTEM
SETTINGS
PAPER TRAY
SETTINGS
ATA
ORWARD
RINT
PRINTER
CONDITION
SYSTEM SETTINGS
PAPER TRAY SETTINGS
TRAY SETTINGS
1/8
PLAIN / 8 x11
OK
PRINT
PAPER TRAY SETTINGS
TYPE / SIZE
SYSTEM SETTINGS
TRAY 1
FAX
I-FAX
COPY
DOC.
FILING
FIXED PAPER SIDE
DISABLE DUPLEX
DISABLE STAPLE
DISABLE PUNCH
1
/
2
TYPE / SIZE
TRAY 2
PER TRAY SETTINGS
PRINT
COPY
I-FAX
DOC.
FILING
FAX
PLAIN / 8 x11
1
/
2
HEAVY PAPER
TYPE.
LETTER HEAD
LABELSPRE-PUNCHED
COLOR
TRANSPARENCY
TYPE OK
SIZE
AUTO-INCH
AUTO-AB
SIZE INPUT
8 X11,8 X11R
A4,A4R,B5,B5R
JAPANESE P/C
X420 Y297
SETTING
1
/
2
1
/
2
NON STANDARD
SIZE
2/2
Copy_SEC.book 23 ページ ２００６年１２月１３日 水曜日 午後３時１分
