Sharp AR-FX8 Spezifikationen PDF herunterladen (Seite 39)

AR-FX8 SIMULATIONS, FAX SOFTWARE SWITCH 6-27

4 5 Not used 0

6 F code relay broadcast

function

Used to set whether relay broadcast transmission is made by receiving F code

relay broadcast instruction from the other party or F code relay broadcast

instruction is not received (even though the relay box number by SUB is

matched on). Though this item is set to "without this function," F code relay

broad cast instruction can be transmitted.

0 Receive

7 F code confidential

reception

Used to set YES/NO of F code confidential reception from the other party (even

though the confidential box number is matched by SUB). Though this item is set

to NO, F code confidential transmission can be made.

0 Receive

8 F code communication

error process

Used to set YES/NO of resend in F code transmission.

When, however, SW59-3 (Recall allow in communication error) is set to 0

(Inhibit), recall is not made.

0 Resend

5 1 F code password

transmission setup

when the other party

has no function of

password

Used when the other party machine has no function of F code password in F

code transmission.

0 Line dis-

connection

with DCN

2,3 Image quality in

reception

(Reflected on DIS, not

reflected on DTC)

Used to set reception image resolution in FAX reception ringing (DIS send). 0 Ultra fine

4-8 Not used 0

6 1 SUB capacity in

reception

Used to set SUB capacity (Bit 49) to "1" in reception (DIS send). 0 YES

2 SEP capacity in

reception

Used to set SEP capacity (Bit 47) to "1" in reception (DIS send) 0 YES

3 Reception PWD/SID

capacity

Used to set PWD/SID capacity (Bit 50) to "1" in reception (DIS send). 0 YES

4 Automatic reduction

send

Used to set whether the transmitted document is reduced or the both ends are

cut when the transmitted document size is greater than the recording paper size

(width) in the other party's machine.

0 Reduction

setup

Send setup

5 Rotation send selection

(A4 A4R)

(LTR LTR-R)

Used to set whether A4 document is transmitted in A3 width (A4) or A4

document is rotated and transmitted in A4R.

0 Rotate Send setup

6 Rotation send selection

(B5R B5)

(16K 16KR)

Used to set whether B5R document is transmitted in A4 width (B5R) or the scan

image is rotated and transmitted in B4 width (B5).

0 Rotate Send setup

No.

Bit

No.

Item Switch selection and function USA Initial value Key

operator

1: F code relay

broadcast instruction

is received from

allowed party.

0: F code relay broadcast

instruction is not received

even from allowed party.

(Judged as

a communication error.)

1: F code confidential

reception inhibited (Judged

as a communication error.)

0: F code confidential

reception allowed.

1: Not resend 0: Resend

1: Send with password 0: Disconnecting of line

with DCN

Bit No. 2 3

Standard 1 1

Fine + Standard 1 0

Super fine + Fine + Standard 0 1

Ultra fine+ Super fine + Fine +

Standard

1: NO (Set to 0) 0: YES (Set to 1)

Send by cutting both edges without

reduction

0 Send by

reduction

1: Send as A3 width

document (A4) without

rotating

0: Send as A4 width

document (A4R) with

rotating

1: Send as A4 width

document (B5R)

without rotating

0: Send as B4 width

document (B5) with

rotating

[06]SIMULATIONS ･ FAXSOFTWARESWITCH.fm 27 ページ２００３年１１月１２日　水曜日　午前９時４５分
