LM10V332 Color STN LCD Module (Model Number: LM10V332) Specifications Spec No.: LC99213A Dated: May 31. 2002

SPEC No. LC99213A MODEL No. LM10V332 PAGE 6 5-2.Interface signals  LCD Table 6 Pin No. Symbol Description Level 1 DL4 Display data si

SPEC No. LC99213A MODEL No. LM10V332 PAGE 7  CCFT Pin No Symbol Description Level 1 HV High voltage line (from Inverter) - 2 NC NC - 3

SPEC No. LC99213A MODEL No. LM10V332 PAGE 8 Fig.1 Dot chart of display area ＲＧＢＲＧＢ ＲＧＢＲＧＢ ＲＧＢＲＧＢ ＲＧＢＲＧＢＲＧＢＲＧＢ ＲＧＢＲＧＢ ＲＧＢＲＧＢ ＲＧＢＲＧＢ(1,1)(1,

SPEC No. LC99213A MODEL No. LM10V332 PAGE 9 Fig.2 Data Input timing chart DL0 LP YD 484h line’s display data 241th line’s display data

SPEC No. LC99213A MODEL No. LM10V332 PAGE 10 Table 7 Interface timing ratings *1 LCD module functions at the minimum frame cycle of 8

SPEC No. LC99213A MODEL No. LM10V332 PAGE 11 t YD LP LP FRM LYH HYH HYS LYS WLPH LS r f LH DH DS WCKH WCKL DU0～ 7 DL0～7 Fig.3 Interface timi

SPEC No. LC99213A MODEL No. LM10V332 PAGE 12 6. Module Driving Method 6-1. Circuit configuration Fig.9 shows the block diagram of the module’s

SPEC No. LC99213A MODEL No. LM10V332 PAGE 13 Because of the characteristics of CMOS driver LSI, the power consumption of the display module goe

SPEC No. LC99213A MODEL No. LM10V332 PAGE 14 7. Optical Characteristics Following spec are based upon the electrical measuring conditions, on

SPEC No. LC99213A MODEL No. LM10V332 PAGE 15 Measuring Spot Size : φ10 mm θx : Angle from “normal” to viewing surface rotated about the horizon

NOTICE This publication is the proprietary of SHARP and is copyrighted, with all rights reserved. Under the copyright laws, no part of this public

SPEC No. LC99213A MODEL No. LM10V332 PAGE 16 (Response Measurement) Ta = 25 ℃ In dark room 　　１ TOPCON BM7 + quartz fiber (Measuring spot

SPEC No. LC99213A MODEL No. LM10V332 PAGE 17 τr : Rise time

SPEC No. LC99213A MODEL No. LM10V332 PAGE 18 Fig. 9 Circuit block diagram Tempareture Compensation Circuit COM Drivers SEG Drivers (Upper) DU

SPEC No. LC99213A MODEL No. LM10V332 PAGE 19 8.Characteristics of Backlight The ratings are given on condition that the following conditions ar

SPEC No. LC99213A MODEL No. LM10V332 PAGE 20 5-2) Operating life The operating life time is 25 000 hours or more at 5.5 mA , at 25℃. (Operating

SPEC No. LC99213A MODEL No. LM10V332 PAGE 21 9. Supply voltage sequence condition 　　１500 1500ms MIN. (NOTE 1) a (NOTE 2)

SPEC No. LC99213A MODEL No. LM10V332 PAGE 22 10. Cautions 1) Industrial(Mechanical) design of the product in which this LCD module will be inc

SPEC No. LC99213A MODEL No. LM10V332 PAGE 23 1. Operator Electrostatic shielding clothes shall be had because it is feared that the static elect

SPEC No. LC99213A MODEL No. LM10V332 PAGE 24 13) Procedure insert mating connector When the mating connector is inserted, it should be paralle

SPEC No. LC99213A MODEL No. LM10V332 PAGE 25 14) This specification describes display quality in case of no gray scale. Since display quality

SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.Suggested applications (if any) are for standard use; See Important Restrictions for limitations o

RECORDS OF REVISION DOC.FIRST ISSUE FEB.17.1999 DATE REF.PAGE PARAGRAPH DRAWING No. REVISED NO. SUMMARY CHECK AND APPROVAL JUL.12.1999 P5,P6

SPEC No. LC99213A MODEL No. LM10V332 PAGE 1  Contents Page 1.Application 2 2.Construction and Outl

SPEC No. LC99213A MODEL No. LM10V332 PAGE 2 1. Application This data sheet is to introduce the specification of LM10V332, Passive Matrix typ

SPEC No. LC99213A MODEL No. LM10V332 PAGE 3 3. Mechanical Specification Table1 Parameter Specifications Unit Outline dimensions 264±0.5(W)×193

SPEC No. LC99213A MODEL No. LM10V332 PAGE 4 4-2.Environment Conditions Table 3 Tstg Topr Item MIN. MAX. MIN. MAX. Remark Ambient temperature

SPEC No. LC99213A MODEL No. LM10V332 PAGE 5 5.Electrical Specifications 5-1. Electrical charasteristics Table 5 Ta=25 ℃ VDD= 5
