SPEC No.

LC99213A

MODEL No.

LM10V332

PAGE

 CCFT

Pin No Symbol Description Level

1 HV High voltage line (from Inverter) -

2 NC NC -

3 GND Ground line (from Inverter) -

 LCD

Used connector : DF9B-31P-1V(HIROSE)

Mating connector : DF9B-31S-1V(HIROSE)

 CCFT

Used connector : BHR-03VS-1(JST)

Mating connector : SM02(8.0)B-BHS(JST)

Except above connector shall be out of guaranty.
