This chapter explains connections and changes to settings that are necessary in the event that the machine is moved.
CONNECTIONS AND SETTINGS AFTER THE
MACHINE IS MOVED
If the machine is moved to a different location or the fax number changes, check the following items and change the
following settings:
Telephone line connection, telephone line type setting, check the main power, check the date and time, change your
sender fax number setting.
CONNECTION TO THE TELEPHONE LINE
Be sure to use the provided telephone line cord to connect the machine to the wall telephone jack. Connect the end of
the line cord that has the core to the "LINE" jack on the machine. Insert the other end (the end without the core) into a
telephone line jack.
10
IF THE MACHINE IS MOVED
Click!
Core
"LINE" jack
Insert the end of the cord with the
core into the "LINE" jack.
