6
(10) Tray 1 (left side)
This holds paper. Up to 1200 sheets of paper can be
loaded.
☞ TRAY SETTINGS FOR TRAY 1 AND TRAY 2 (page
27)
(11) Tray 2 (right side)
This holds paper. Up to 800 sheets of paper can be
loaded.
☞ TRAY SETTINGS FOR TRAY 1 AND TRAY 2 (page
27)
(12) Tray 3
This holds paper. Transparency film, tab paper, and
other special media can also be loaded. Up to 500 sheets
of paper can be loaded.
☞ TRAY SETTINGS FOR TRAY 3 AND TRAY 4 (page
30)
(13) Tray 4
This holds paper. Up to 500 sheets of paper can be
loaded.
☞ TRAY SETTINGS FOR TRAY 3 AND TRAY 4 (page
30)
(14) Tray 5 (when a large capacity tray (MX-LCX2) is
installed)*
This holds paper. 8-1/2" x 11" or A4 paper can be loaded.
Up to 3500 sheets of paper can be loaded.
☞ TRAY SETTINGS OF TRAY 5 (LARGE CAPACITY
TRAY) (page 33)
(15) Tray 5 (when a large capacity tray (MX-LCX3) is
installed)*
This holds paper. 8-1/2" x 11" to 12" x 18" (B5 to A3W)
paper can be loaded. Up to 3000 sheets of paper can be
loaded.
☞ TRAY SETTINGS OF TRAY 5 (LARGE CAPACITY
TRAY) (page 33)
* Peripheral device.
(10) (11)(12) (14) (15)
(13)
