This chapter explains how to use an extension phone to make voice calls and receive a fax after talking with the other

party.

CONNECTING AND USING AN EXISTING

PHONE (Extension Phone Connection)

You can connect an existing extension phone to the machine.

The phone can be used for voice calls and to start fax reception on the machine.

As an example, you can make a phone call using the existing phone, speak to the other party, and then press the

[BLACK & WHITE START] key ( ) to fax an original that has been placed to that party. You can also press the

[BLACK & WHITE START] key ( ) when an original is not placed to receive a fax.

Connect the extension phone as shown below.

USING AN EXTENSION PHONE

• Connect an extension phone that has a modular jack. Use standard phone line cable to connect the phone. If other than a

standard phone line cable is used, the connection may not work correctly.

• If the plug on the telephone line cord does not fit into the jack on your extension phone, contact your dealer or nearest

SHARP Service Department.

Attach the provided core to

your extension telephone cord

and then connect the cord to

the machine.

Existing extension

phone (example)

Extension phone jack

Click!

Core

Make sure you hear a "click"

sound indicating that the

cord is securely connected.
