13
Total Count
This function shows the page count in each mode. Touch the [Total Count] key to use the function.
Job Count
This displays or prints out the counts of all jobs.
Device Count
This is used to display or print the counts of the peripheral devices installed on the machine.
• 11" x 17" (A3) size paper is counted as two sheets.
• Each sheet of paper used for automatic two-sided copying is counted as two pages (11" x 17" (A3) paper is counted as
four pages).
• An entered paper size of 5-1/8" (384 mm) or larger is counted as two pages. (Four pages when two-sided copying is used.)
• Pages printed directly from the machine such as list prints are included in the "Other Prints" count.
• The items displayed (or printed) will vary depending on the machine specifications and peripheral devices installed.
• Document feeder
Each sheet is counted as two pages when two-sided scanning is performed.
• Stapler (when a finisher or saddle stitch finisher is installed)
Two-position stapling and pamphlet stapling are counted as "2".
• The items displayed (or printed) will vary depending on the machine specifications and peripheral devices installed.
