78
5
Close the waste toner box compartment
cover.
After closing the cover, make sure that the message no longer
appears.
Caution
• Do not throw the waste toner box into a fire. Toner may fly and cause burns.
• Store the waste toner box out of the reach of small children.
When replacing the waste toner box, be aware that it may soil your clothes or the immediate surroundings.
