03 ROM & RAM

check mode

This mode is used to perform ROM check sum and RAM read/write test.

The result is shown with the buzzer and the LCD.

No error: NO ERROR/ No buzzer

ROM error : ROM ERROR / Buzzer once

RAM error : RAM ERROR / Buzzer twice

03:ROM/RAM CHECK

04 Signal send mode This mode is used to send various signals to the line. The FAX signal is sent in

the level set with the soft switch.

There are the following kinds of signals:

04:SIGNAL SEND

10 Image memory

clear mode (Only

the image data is

cleared.)

This mode is used to clear the image data memory (DRAM). 10:IMAGE MEM CLEAR

14 Dial test /

adjustment mode

(Pulse 10 pps)

This mode is used to dial in dial pulse (10PPS) and to set the pulse make ratio

adjustment value.

The range of make ratio variable range: -8% ∼ +7%

The setup is reflected on the adjustment value area of the soft switch.

The dialed number is fixed to “1590.”

14:DIAL TEST 10 PPS

16 Dial test mode

(Tone)

This mode is used to dial with DTMF.

The number to be dialed is fixed to “123456789∗0#”.

16:DIAL TEST TONE

21 Print out soft

switch mode

This mode is used to print the report on the current soft switch setup. 21:PRINT SOFT SW

42 FAX Panel check

mode

This mode is used to check the keys and the LED on the FAX panel.

When any key on the FAX panel other than the STOP key is pressed, the name

of the pressed key is displayed on the LCD.

The LED’s on the FAX panel are lighted one by one sequentially.

When any change is made on a sensor in the SPF section, the sensor name as

well as its ON/OFF status is displayed on the LCD.

42:FAX PANEL TEST

43 Signal detect mode This mode is used to detect signals in the line, and the detected signal name is

displayed on the LCD. The signals to be detected are CNG, DTMF, and silent.

The detection conditions conform to the soft switch setup.

43:SIG. DETECT

44 Long distance

comm. Select mode

This mode is used to specify the other party FAX numbers registered in the one-

touch/speed dial, with which communication errors occur frequently due to poor

line conditions

To the specified parties, the max. transmission speed is compulsorily reduced to

stabilize the communication line.

The speed is available in 9600BPS and 4800BPS.

44:LONG DIST COMM

C. Operating procedures in each mode

(1) Soft SW change method

Procedure LCD Operation

1 Press FUNCTION, 9, ∗, 8, #, 7. DIAGNOSTIC MODE

ROM VERSION = <version>

2 Press ENTER. DIAGNOSTIC MODE

SELECT MENU(← →)

3 Press 0, 1. SW # =

4 Enter the SW No. (2 digits) to be changed. SW # = 10

5 Press ← / → to shift the cursor to the bit to be

changed. (The left edge is Bit No. 1.)

SW10 = 00010101

bit # = 12345678

1 No signal ( OFF HOOK state)

2 DTMF (0,1,2,3,4,5,6,7,8,9,*,#)

3 14400 bps (V.17) (00000000b, 11111111b, 01010101b)

4 12000 bps (V.17) (00000000b, 11111111b, 01010101b)

5 9600 bps (V.17) (00000000b, 11111111b, 01010101b)

6 7200 bps (V.17) (00000000b, 11111111b, 01010101b)

7 9600 bps (V.29) (00000000b, 11111111b, 01010101b)

8 7200 bps (V.29) (00000000b, 11111111b, 01010101b)

9 4800 bps (V27ter) (00000000b, 11111111b, 01010101b)

10 2400 bps (V27ter) (00000000b, 11111111b, 01010101b)

11 300 bps (FLAG) (00000000b, 11111111b, 01010101b)

12 2100 Hz (CED)

13 1100 Hz (CNG)

AR-F152

9 – 15
