3) Store the pressure plate lock which has been removed in

step 2 and the screw which has been removed when un-

packing (see page 4-2, step 2 of REMOVING PROTEC-

TIVE PACKING MATERIALS) in the front of the paper tray.

To store the pressure plate lock, rotate the lock to fix it on

the relevant location.

4) Adjust the paper guides on the paper tray to the copy paper

width and length.

Squeeze the lever of paper guide (A) and slide the guide to

match with the width of the paper.

Move paper guide (B) to the appropriate slot as marked on

the tray.

5) Fan the copy paper and insert it into the tray. Make sure the

edges go under the corner hooks.

Note: Do not load paper above the maximum height line ( ).

Exceeding the line will cause a paper misfeed.

6) Gently push the paper tray back into the copier.

Note: After loading copy paper, to cancel the blinking “P”

without restarting copying, press the clear ( ) key.

The “P” in the display will go out and the ready ( ) in-

dicator will light up.

9. Connecting the Telephone Line Cord

Plug one end of the telephone line cord into the jack on the unit

marked “LINE” .Plug the other side into a standard (RJ11C)

single-line telephone wall jack. Be sure not to plug this line cord

into the “TEL” jack. The “TEL” jack is used to attach an exten-

sion telephone or answering machine to the unit. (See “Con-

necting Other Devices” in this chapter for details.)

Note: If your area experiences a high incidence of lightning or

power surges, we recommend that you install surge

protectors for the power and telephone lines. Surge

protectors can be purchased from your dealer or at most

telephone specialty stores.

10. Connecting Other Devices

If desired, an answering machine or external telephone can be

connected to the unit through the telephone jack, labeled “TEL”,

on the rear of the unit.

● Connecting an answering machine to the unit allows you to

receive both voice and fax messages when you are out. To

use this feature, first change the outgoing message of your

answering machine, and then set the reception mode of the

unit to “A.M”. (Answering Machine mode) when you go out.

Note: If you are using distinctive ringing with an answering

machine, you do not need to follow the procedure

described below. (Please note that when distinctive ring-

ing is used, the answering machine must be connected

to a separate wall jack, not to your fax.)

The outgoing message of your answering machine should be

changed to inform callers who want to send a fax to press their

FAX START key.

Comments:

1) It is advisable to keep the length of the message under 10

seconds. If it is too long, you may have difficulty receiving

faxes sent by automatic dialing.

2) Your callers can even leave a voice message and send a

fax message on the same call. Modify your outgoing mes-

sage to explain that this can be done by pressing their FAX

START key after leaving their voice message.

● You can connect an extension phone to the unit to make and

receive calls like any other extension phone on your line.

Even if you pick up the extension phone and hear a fax tone,

the unit will automatically cut in and take over the line. Note,

however, that if you also have a PC modem on the same

line, you must turn on the Remote Reception function, and

deactivate the Fax Signal Receive function. See “Setting Up

the Unit for Use with a PC Modem” and “Using the Remote

Reception Function” in Chapter 2).

Note: The Remote Reception function is initially set to “ON”.

11. POWER TO COPIER

1) Ensure that the power switch of the copier is in the OFF

position. Insert the attached power cord into the power cord

socket at the rear of the copier.

2) Plug the other end of the power cord into the nearest outlet.

Paper guide (B)

Paper guide (A)

LINE

TEL

AR-F152

5 – 4
