MX-M182 GENERAL 1-1

[1] GENERAL

1. Note for servicing

Pictogram

The label ( ) in the fusing area of the machine indicates the

following:

: Caution, risk of danger

: Caution, hot surface

A. Warning for servicing

•The fusing area is hot. Exercise care in this area when removing

misfeed paper.

•Do not disassemble the laser unit. Do not insert a reflective material

such as a screwdriver in the laser beam path.



It may damage eyes by reflection of laser beams.

B. Cautions for servicing

•Do not switch the machine rapidly on and off. After turning the machine

off, wait 10 to 15 seconds before turning it back on.

•Machine power must be turned off before installing any supplies.

•Place the machine on a firm, level surface.

•Do not install the machine in a humid or dusty location.

•When the machine is not used for a long time, for example, during

prolonged holidays, turn the power switch off and remove the power

cord from the outlet.

•When moving the machine, be sure to turn the power switch off and

remove the power cord from the outlet.

•Do not cover the machine with a dust cover, cloth or plastic film while the

power is on. Doing so may prevent heat dissipation, damaging the

machine.

•Use of controls or adjustments or performance of procedures other than

those specified herein may result in hazardous laser radiation

exposure.

•The socket-outlet shall be installed near the machine and shall be easily

accessible.

C. Note for installation place

Improper installation may damage the machine. Please note the

following during initial installation and whenever the machine is moved.

Caution : If the machine is moved from a cool place to a warm place,

condensation may form inside the machine. Operation in this

condition will cause poor copy quality and malfunctions. Leave

the machine at room temperature for at least 2 hours before

use.

Do not install your machine in areas that are:

•damp, humid, or very dusty

•poorly ventilated

•exposed to direct sunlight

•subject to extreme temperature or humidity changes, e.g., near an air

conditioner or heater.

The machine should be installed near an accessible power outlet for

easy connection and disconnection.

Be sure to connect the power cord only to a power outlet that meets the

specified voltage and current requirements. Also make certain the outlet

is properly grounded.

Note : Connect the machine to a power outlet which is not used for other

electric appliances. If a lighting fixture is connected to the same

outlet, the light may flicker.

Be sure to allow the required space around the machine for servicing

and proper ventilation.

20 cm

)

20 cm

)

20 cm (8

)
