MX-M182 SIMULATIONS 7-25

26 51 Copy temporary stop function setting

Used to set whether copying is stopped temporarily when the paper exit tray full is detected. When the

electronic sort function is used, paper exit of 250 sheets (*1) or more can be used for one copy job. If, at that

time, copying (paper discharge) is continued with the tray full, a paper exit jam may occur. To avoid this,

copying is temporarily stopped by this setting.

(*1) 150 sheets when the job separator is installed.

[CA] key: Exits the simulation mode.

[INTERRUPT] key: Shifts to the sub code input window.

Default:

54 LCD contrast PWM duty setting

Used to set the PWM duty (brightness) at the center value of LCD contrast.

* Setting range: 30-70

* When [OK] key or [START] key is pressed, the set value of LCD contrast is immediately reflected.

[CA] key: Exits the simulation mode.

[INTERRUPT] key: Shifts to the sub code input window.

Default:

56 Life correction ON/OFF setting

The image correction ON/OFF setting is made according to the usage level (life) of developer.

When this simulation is executed, the list of the modes and the current set value are displayed on the LCD.

Select an item to be changed with the arrow keys, and change the set value to the required value.

(1=ON [Enable], 0=OFF [Disable])

When [OK] key or [START] key is pressed, the setting is saved to the EEPROM.

[CA] key: Exits the simulation mode.

[INTERRUPT] key: Shifts to the sub code input window.

Default:

1: 1

2: 1

3: 1

4: 1

5: 1

6: 1

7: 1

8: 1

60 [FAX] key Enable/Disable setting

Used to set Enable/Disable of the [FAX] key when the FAX PWB is not installed.

Though this setting is set to Enable, if the FAX PWB is not installed, a message of "FAX PWB is not

installed" is displayed.

* When the FAX PWB is installed, the display shifts to the FAX window regardless of this setting.

[CA] key: Exits the simulation mode.

[INTERRUPT] key: Shifts to the sub code input window.

Default:

Main

code

Sub

code

Contents Remark

Sim26-51 COPY STOP

1:COPIES STOP

0=NON STOP

1=STOP

[ 0-1]

Display: Setting

0 : Temporary stop cancel

1 : Temporary stop

Sim26-54 LCD DUTY

1:LCD PWM DUTY

[ 30- 70]

Sim26-56 LIFE SET

1:AE1

2:AE2

3:TEXT

1/3 [ 0- 1]

Sim26-56 LIFE SET

4:PHOTO 1

5:PHOTO 2

6:AE(TS)1

2/3 [ 0- 1]

Sim26-56 LIFE SET

7:AE(TS)2

8:TEXT(TS)

3/3 [ 0- 1]

Screen display : adjustment mode

1: AE1

2: AE2

3: TEXT

4: PHOTO 1

: AE1 life correction

: AE2 life correction

: TEXT life correction

: PHOTO (Error diffusion) life correction

Screen display : Adjustment mode

5:PHOTO 2

6:AE(TS)1

7:AE(TS)2

8:TEXT(TS)

: PHOTO(Dither) life correction

: TSAE1 life correction

: TSAE2 life correction

: TSTEXT life correction

Sim26-60 FAX KEY

1:FAX KEY MODE

[ 0- 1]

FAX PWB

Setting Yes No

0 (Enable) FAX window display FAX not-installed display

1 (Disable) FAX window display Error beep sound
