www.turnerbiosystems.com 3

1.1.3 Unpacking and Inspection

Upon receiving the Modulus™ Microplate Reader, inspect it carefully for any damage to

the exterior such as scratches and/or dents. Make certain all accessories are included.

Refer to the checklist shipped with the instrument for order-specific items. Save all

packaging materials, if possible, in case the instrument needs to be shipped to a service

center in the future.

Content

Modulus

™

Microplate Reader

Instrument

Non-Sterilized 96-Well

Microplates (optional starter kit)

Power Line Cord

Waste Collection Tray (included

with injector system)

Power Supply Brick, 24V, 60W

Outlet Injector Tube Assembly

(included with injector system)

USB Flash Drive, 264MB

DB-15 Serial Cable (included

with injector system)

Fluorescence Optical Kits

(included with fluorescence

module)

Injector System (optional)

Luminescence Standard Light

Plate (optional)

1.1.4 Set Up

CAUTION: Remove all of the foam packaging from inside the instrument

before initial power up. Failure to do so may result in damage to the

electronics.

1. Place the Modulus™ Microplate Reader on a flat, level surface. Leave at least 7.5 inches

(19 cm) of clearance in front of the instrument to allow the instrument door to open

without hindrance. Position the instrument so that the touch screen faces outward.

2. Manually open the instrument door and remove the foam packing from inside of

the instrument. The packing material is used to secure the optical heads and Microplate

Sample Tray during shipping.

Figure 1-1: A Complete Modulus™ Microplate System
