Main code Sub code Content

07 01 Warm-up display and aging with jam

(Operation/Procedure)

1. When the simulation is executed, warming up is started.

2. Warm-up time is counted and displayed every second on the copy quantity display.

3. After completion of warm-up, the time count is stopped and the ready lamp is lighted.

4. Press the clear key to clear the warm-up time display, set the copy quantity, and press the START key, and

the machine will copy the set quantity repeatedly.

06 Intermittent aging

(Operation/Procedure)

1. When the simulation is executed, warming up is started.

2. After completion of warm-up, the ready lamp is lighted.

3. Set the copy quantity and press the START key, and the machine will copy the set quantity repeatedly.

4. After 3 sec of the interval time from completion of copying the set quantity, the machine will resume copying.

5. The above operation 4 is repeated.

08 01 Developing bias

(Operation/Procedure)

When the START key is pressed, the developing bias is outputted for 30 sec.

02 Main charger (Grid high)

(Operation/Procedure)

When the START key is pressed, the main charger output is supplied for 30 sec in the grid voltage HIGH mode.

03 Grid voltage (Low)

(Operation/Procedure)

When the START key is pressed, the main charger output is supplied for 30 sec in the grid voltage LOW mode.

06 Transfer charger

(Operation/Procedure)

When the START key is pressed, the transfer charger output is supplied for 30 sec.

10 None Toner motor aging

(Operation/Procedure)

When the START key is pressed, the toner motor output is supplied for 30 sec.

14 None Cancel of troubles other than U2

(Operation/Procedure)

After canceling the trouble, the simulation is also automatically canceled.

16 None Cancel of U2 trouble

(Operation/Procedure)

1. When the START key is pressed, the EEPROM total counter check sum is rewritten and the trouble is

canceled.

2. After canceling the trouble, the simulation is also automatically canceled.

20 01 Maintenance/mini-maintenance counter clear

When the Print switch is pressed, the maintenance counter is cleared, and 000000 is displayed. When the

destination has been set to Japan AB series, the mini-maintenance counter is cleared.

21 01 Maintenance cycle setup

The currently set maintenance cycle code is displayed (initial display), and the set data is stored.

02 Mini-maintenance cycle setup (Valid only when the destination is set to Japan AB series.)

The current set code of maintenance cycle is displayed (Initial display), and the set data is stored.

Code Setup

0 3,000 sheets

1 6,000 sheets

2 9,000 sheets

3 13,000 sheets

4 25,000 sheets

5 Free (999,999 sheets) ∗ Default

Code Setup

0 5,000 sheets ∗ Default

1 10,000 sheets

2 Free (999,999 sheets)

AR-F152

9 – 3
