1-67
BEFORE USING THE MACHINE
Contents
REPLACING THE WASTE TONER BOX
The waste toner box collects excess toner that is produced during printing. When the waste toner box becomes full,
"Replace used toner container." will appear. Follow the procedure below to replace the waste toner box.
1
Open the front cover.
2
Release the used waste toner box.
Press the waste toner box release button.
The waste toner box will fall forward as shown at left. Wait until
the box comes to a stop.
Keep the replacement cleaner that has not been used.
Store it at the top of the waste toner box.
3
Remove the waste toner box.
Hold the box by both hands and lift it up slowly.
If the waste toner box falls too far forward, it will not be possible
to remove it. (Remove the box when it is at an angle of about
30 degrees.)
