TROUBLESHOOTING
Contents
(12) Paper misfeed in the paper pass unit
Pull out the paper pass unit
and remove the misfed
paper.
Check the paper reversing
section inside the tray and
remove any misfed paper.
(13) Paper misfeed in the large capacity tray
While holding the tray
release lever, carefully slide
the large capacity tray away
from the main unit until it
stops.
(14) Paper misfeed in the saddle stitch
finisher (bottom)
Open the front cover.
Move lever (A) to the right
and remove the misfed
paper.
Move lever (B) to the right
and remove the misfed
paper.
Remove the misfed paper.
While pulling the lever, slide
the saddle stitch finisher to
the left until it stops.
Remove the misfed paper.
(A)
(B)(B)
