BEFORE USING THE MACHINE
Contents
Replacing the staple cartridge (saddle stitch unit)
Before starting this procedure, remove all output from the output tray of the saddle stitch finisher. Do not replace
removed output in the output tray.
1
Open the side cover.
2
Remove the empty staple cartridge.
3
Load the new staple cartridge.
Remove the cover from the staple cartridge and install the
cartridge.
4
Close the side cover.
Make a test print or copy using the saddle stitch function to verify that stapling takes place correctly.
