2-129
COPIER
Contents
COPYING ORIGINALS OF DIFFERENT SIZES
(Mixed Size Original)
Even when 8-1/2" x 14" (B4) originals are mixed in with 11" x 17" (A3) originals, all originals can be copied at once. When
scanning the originals, the machine automatically detects the size of each original and uses paper appropriate for that size.
When mixed size original is combined with auto ratio selection, the ratio is adjusted individually for each original according
to the selected paper size, enabling output on a uniform paper size.
When mixed size original is combined with auto ratio selection
(Auto ratio selection and 11" x 17" (A3) are selected)
There are two settings for mixed size originals.
Same Width
Use this setting for originals that are different sizes but have sides that are the same length. The originals
are inserted in the document feeder tray with the sides that are the same length aligned together on the left.
• 11" x 17" and 8-1/2" x 11" • 8-1/2" x 14" and 8-1/2" x 11"R • 8-1/2" x 14" and 5-1/2" x 8-1/2"
• 8-1/2" x 13" and 8-1/2" x 11"R • 8-1/2" x 13" and 5-1/2" x 8-1/2" • 8-1/2" x 11"R and 5-1/2" x 8-1/2"
• A3 and A4 • B4 and B5 • A4R and A5
Different Width
Use this setting when the originals are different sizes and do not have sides that are the same length. This
setting can only be used for the following combinations of sizes:
• 11" x 17" and 8-1/2" x 14" • 11" x 17" and 8-1/2" x 13" • 11" x 17" and 5-1/2 x 8-1/2"
• A3 and B4 • A3 and B5 • B4 and A4 • A4 and B5 • B4 and A4R • B4 and A5
• B5 and A4R • B5 and A5
Originals
Copies
11" x 17"
8-1/2" x 14"
11" x 17"
8-1/2" x 14"
Originals
Copies
An 8-1/2" x 14" (B4) size original will be
enlarged to 11" x 17" (A3) size.
11" x 17"
8-1/2" x 14"
11" x 17"
11" x 17"
